Eye and Eye Webbing Sling
1. Product Overview
The eye and eye webbing sling — also known as the flat eye-eye webbing sling or webbing sling with two eyes — is a versatile and durable lifting tool designed for various lifting applications. It is made from high-quality polyester webbing and offers excellent strength, durability and flexibility.
The sling features loops or eyes at each end, allowing for easy attachment to lifting equipment. The eyes are reinforced for added strength and stability, ensuring a secure connection during lifting operations.
With a flat webbing design, the sling evenly distributes the weight of the load, reducing stress on the lifting points. This helps prevent damage to the load and ensures a more secure lifting operation. Its smooth, soft surface protects the load from abrasion and friction, and its flexibility allows it to conform to the shape of the load, maximizing stability and load-bearing capacity.
The eye and eye webbing sling is available in various lengths and load capacities and is color-coded for easy identification of capacity, promoting safety and efficiency in the workplace.
2. Key Features & Benefits
Two Reinforced EyesLoops at each end, reinforced for added strength and stable, secure attachment to hooks and equipment.
Even Load DistributionFlat webbing design spreads the load weight evenly, reducing stress on lifting points.
Load ProtectionSmooth, soft surface protects the load from abrasion and friction during lifting.
Flexible & ConformingConforms to the shape of the load for maximum stability and load-bearing capacity.
Color-Coded CapacityEasy identification of load capacity for safety and efficiency at the worksite.
Custom OptionsVarious lengths and load capacities to suit different lifting requirements; OEM/ODM supported.
3. Construction & Specifications
| Item | Specification |
|---|---|
| Material | High-quality polyester webbing (flat woven) |
| End Fittings | Two reinforced soft eyes (loops) at each end |
| Load Surface | Smooth, soft surface to protect the load from abrasion and friction |
| Capacity Identification | Color-coded per standard for easy recognition |
| Length | Various standard lengths; custom on request |
| Load Capacities | Various WLL options to suit lifting requirements |
| Standards | EN 1492-1 / ASME B30.9 (flat woven webbing slings) |
| Safety Factor | 7:1 (standard) |
| Certification | Test certificate available; CE and third-party inspection supported |
4. Hitch Configurations & Load Factors
Eye and eye webbing slings support three standard hitch configurations. Always apply the correct load factor when planning a lift.
| Hitch Type | Load Factor | Application Notes |
|---|---|---|
| Vertical (Straight) | 1.0 × WLL | Single-leg straight lift; sling vertical, load suspended directly below the hook. |
| Choker Hitch | 0.8 × WLL | Sling wrapped around the load, one eye passed through the other; choker angle ≤120°. |
| Basket Hitch | 2.0 × WLL | Both eyes on the hook, sling cradles the load; maximum capacity configuration, load must be balanced. |
WARNING: Always derate the WLL according to hitch type and angle. Choker angle must not exceed 120°. Never exceed the rated capacity.
5. Industries & Applications
With proper handling and maintenance, the eye and eye webbing sling provides reliable lifting solutions across industries:
Construction — steel beams, precast panels, formwork and building material handling.
Manufacturing — production line lifting, machine parts and heavy component transfer.
Logistics & Warehousing — cargo handling, container loading and palletized goods.
General Material Handling — pipes, bundles, coils and finished goods with surface protection.
6. Inspection, Care & Service Life
6.1 Pre-Use Visual Inspection (Every Lift)
Examine the full webbing length and both eyes for cuts, tears, abrasion or broken stitching.
Check for chemical attack indicators — discoloration, stiffening or surface flaking.
Inspect for heat or friction damage — melting, glazing, charring or fused fibers.
Verify the identification label is present, legible and matches the intended load and hitch.
Confirm the eye loops are not stretched, deformed or frayed — discard if the shape is distorted.
6.2 Periodic Examination & Storage
A competent person must carry out a detailed inspection at least every 6 months (or more frequently in harsh environments) per applicable regulations and standards, with written records maintained.
Store flat or hung on sling racks, in a cool, dry, ventilated area away from sunlight and chemicals.
Clean with mild soap and clean water only — never use chemical solvents or abrasive methods.
Do not drag slings over rough surfaces or sharp edges; use edge protectors when necessary.
There is no fixed service life — discard is based on condition, not age, as determined by a competent person.
7. Customization Services
Custom lengths, widths and load capacities.
Custom label printing, customer logos and color coding.
Sampling, OEM/ODM and low MOQ available.
Export packing (carton / wooden case / woven bag) as required.
8. Frequently Asked Questions
What is the difference between an eye and eye sling and an endless sling?
An eye and eye webbing sling is a flat band with a reinforced eye at each end for hook attachment. An endless webbing sling is a closed continuous loop without eyes. Choose by your rigging configuration and standard.
Are the eyes strong enough for heavy loads?
Yes. Both eyes are reinforced with additional stitching for added strength and stability, ensuring a secure connection during lifting operations.
How do I know the load capacity?
Each sling carries a sewn-in, color-coded identification label showing the WLL. Capacity color codes follow EN 1492-1 for instant recognition.
Can you supply custom sizes?
Yes. Various lengths and load capacities are available, and custom dimensions, labels and logos can be produced with OEM/ODM service.
